JZP-6.0-SC1 Rubber Shock Absorber The Ideal Solution for Vibration Isolation in Harsh Environments

Xi'an Hoan Microwave Co., Ltd.
Trust Seal
Verified Supplier
Credit Check
Supplier Assessment
Contact Now

JZP-6.0-SC1 Rubber Shock Absorber The Ideal Solution for Vibration Isolation in Harsh Environments

  • 1
  • 2
  • 3

Brand Name : Hoan

Model Number : JZP-6.0-SC1

Certification : ISO9001:2015

Place of Origin : Shaanxi, China

MOQ : 4 piences

Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram

Supply Ability : 4,pience,7

Delivery Time : 7

Product Load Capacity : Customizable

Material : Rubber

Vibration Reduction : High

Warranty : 1 Year

Features : Anchoring Holes; Oil Resistant

Structure : Solid

Wire Diameter : 0.5mm

Height : 50mm

Maximum Deflection : 1 inch

Pressure Range : High

Strand Construction : 7 x 19

Compression : Customized

Core Components : Bearing

Flexibility : Flexible

Contact Now

JZP-SC1 Series
The performance parameters of the JZP series friction damping isolators are excellent. It has a wide range of operating frequencies, which can adapt to the vibration frequencies of different equipment and effectively isolate the vibration of various frequencies. This series of products has good anti-damp heat, anti-salt spray, anti-mildew, high and low temperature resistance and other properties, can work stably in high and low temperature, chemical pollution and other harsh environments, can be widely used in airborne, vehicle-mounted, ship-borne and other electronic and mechanical equipment, computers and instruments and meters vibration isolation buffer, missile satellite carrier, navigation and launch system safety protection and other fields.


The JZP series of vibration isolators offers a number of significant performance advantages. First of all, it has demonstrated excellent capabilities in terms of vibration isolation performance. For low-frequency vibrations, it can accurately identify and effectively isolate to avoid equipment resonance caused by low-frequency vibrations. Low-frequency vibrations are often difficult to isolate due to their long wavelength and special energy propagation mode, but the JZP series vibration isolators can cope with this challenge well. At the same time, it also plays a significant attenuating effect on high-frequency vibrations. The high-frequency vibration isolation capability of this isolator can protect many electronic devices where high-frequency vibrations can cause signal interference, loose components, and other problems.

As a professional high-tech enterprise, Xi'an Hoan Microwave Co., Ltd. has profound technical accumulation and rich experience in the design, development and production of vibration isolators. The company has a number of senior scientific and technological personnel engaged in the research and development of electronic products, and is equipped with a number of high-precision CNC lathes and various electrical performance testing equipment, with good machining capabilities and strict quality control system, to ensure the high quality and reliability of JZP series friction damping isolators.

Product dimensions
JZP-6.0-SC1 Rubber Shock Absorber The Ideal Solution for Vibration Isolation in Harsh Environments

Series

D

(mm)

H±1

(mm)

h

(mm)

A±0.2

(mm)

B

(mm)

dd2R

b

(mm)

h1

(mm)

JZP-SC1603621.75060M5Φ5.55283.4


Product parameters
JZP-6.0-SC1 Rubber Shock Absorber The Ideal Solution for Vibration Isolation in Harsh Environments
JZP-6.0-SC1 Rubber Shock Absorber The Ideal Solution for Vibration Isolation in Harsh Environments

Model

Nominal Load

(KG)

Deflection

Working Temperature

(℃)

Resonant Frequency

(Hz)

Damping ratioImpact test

Expiration date

(year)

JZP-3.2-SC13.2≤0.3-45~+6541.5±5≥0.13100G12次8
JZP-4.2-SC14.2
JZP-5.2-SC15.2
JZP-6.0-SC16.0
JZP-7.0-SC17.0
JZP-7.5-SC17.5
JZP-9.0-SC19.0
JZP-10.5-SC110.5
JZP-13.5-SC113.5
JZP-15-SC115


FAQ
1.Q:Are you a manufacturer or a trading company?
A: We are a manufacturer, not a trading company. We produce our products in our own facilities, ensuring full control over the quality and production process. This allows us to offer competitive pricing and customized solutions directly to our clients.

2.Q:Can you customize products for us?
A:Yes, we have the capability to customize our products to meet your specific needs. Please contact us with your requirements, and our team will work with you to create a tailored solution that fits your preferences.

3.Q:What is the lead time?
A:Sample will usually take 2 to 5 days.For the mass production,it will estimated take 7 to 20 day, Faster delivery when our factory has stock.

4.Q:Can I get some samples before place order and how long for a sample?
A:Yes, sample order is accepted

5.Q:How is your shipping?
A:1)worldwide shipping service available
2)please contact before order as shipping cost varies time to time.

6.Q:Do you offer discounts for bulk orders?
A:Yes, we offer discounts for bulk orders. The discount percentage may vary depending on the order quantity.


laboratory
